Specifications 1:
Helmet
|
|
Optical class:
1/1/1/1
|
|
Viewing area:
107 x 75 mm
|
|
Cartridge size:
156 x 123 x33 mm
|
|
Arc sensor:
4
|
|
Light state (DIN):
DIN 4
|
|
Cutting shade:
5 ~ 8
|
|
Dark state:
variable shade 5 ~ 8 / 9 ~ 13
|
|
Shade control:
internal
,
digital display control
|
|
Power on/off :
manual on/off; auto-off
|
|
Sensitivity setting:
digital display control
|
|
Power supply:
solar cell, 2× CR2450 lithium battery replaceable
|
|
Low battery indicator:
Yes, Digital display
|
|
Switching time (light to dark):
1/25000 sec.
|
|
Delay time (dark to light):
0.1 - 1.0s
|
|
Low amperage TIG rated:
≥ 2 amps (DC); ≥ 2 amps (AC)
|
|
Grinding:
Yes
|
|
Grind state:
DIN 4
|
|
Operating temperature:
-5°C ~ 55°C
,
-5°C ~ 55°C
|
|
Storage temperature:
-10°C ~ +55°C
|
|
Helmet material:
High impact resistance nylon
|
|
MMA welding applications:
SMAW
|
|
TIG welding applications:
GTAW-DC / GTAW-AC / GTAW-P DC / GTAW-P AC
|
|
MIG welding application:
GMAW (MIG/MAG) / GMAW-P
|
|
Cutting welding application:
PAC / CAC-A / OC
|
|
Other welding application:
PAW / OFW
|
|
Specifications 2:
Respirator
|
|
Filter efficiency:
99,997%
|
|
Storage temperature:
-10°C to 55°C
|
|
Airflow:
min. design 165+lpm (5.8+cfm); Low speed 170+lpm (6+cfm); High speed 210+lpm (7.4+cfm)
|
|
Charging time:
1 hour
|
|
Battery duration:
9h (170+lpm); 5-6 h (210+lpm)
|
|
Battery type:
Rechargeable
|
|
Battery capacity test:
-
|
|
Battery technology:
Lithium-ion
|
|
Charge cycles:
≥500
|
|
Permanent UV/IR protection:
up to DIN16
|
